SOME OF OUR EQUIPMENT

Flight near people, within 100 feet (30m) and up to 16.4 feet (5m)

​

Controlled airspace

Designed and adapted to fly in most environments

Whether for the inspection of structures, wind turbines, solar panels, bridges or for search and rescue, our drones are

able to help you no matter what.

​

Advantages

• Very fast deployment.

• Flight time varying between 24 to 35 minutes per stack.

• IP43 protection rating to fly in multiple

• environments.

• Operating temperature between  -20 to 45 ° C.

• Payload capacity between 1.84 and 2 kilograms.

• Resistance to winds over 45  kilometers per hour.

• Top speed ranging from 60 to 80 kilometers per hour.

It is compatible with eight standard M4 / 3 lenses (including zooms) with focal lengths ranging from 9mm to 45mm (equivalent to 18 - 90mm on a 35mm camera) for more creative flexibility. The Inspire 2's new image processing system, CineCore 2.0, gives the Zenmuse X5S the ability to shoot 5.2K 30 fps CinemaDNG and Apple ProRes *, 4K 60 fps H.264 and 4K 30 fps H .265 (both at 100 Mbps). Burst mode continues DNG at a frame rate of 20 fps with 20.8 MP frames. The Zenmuse X5S has been designed to keep pace with the working conditions of aerial imagery professionals.

​

Lens option

• DJI MFT 15mm / 1.7 ASPH

• Olympus M.Zuiko 25mm / 1.8

• Olympus M.Zuiko 45mm / 1.8

• Olympus M.Zuiko 9-18mm / 4.0-5.6

The Zenmuse X4S is a camera with a one-inch sensor, allowing to capture more light and thus improve the image quality.

It has a resolution of 20 megapixels and has an ISO of maximum 12,800 (increased image sensitivity in low light). The dynamic range is one stop greater than the Zenmuse X3.

Its signal-to-noise ratio and color sensitivity are increased thanks to an additional 1.5 diaphragm.

The Zenmuse X4S has a compact lens designed by DJI with low dispersion and distortion and a 24mm equivalent lens. This high-resolution lens, which offers an 84 ° field of view, makes the Zenmuse X4S a camera suited to both aerial images and ground shots.

​

It can produce 5.2K to 4K oversampling videos in real time and thus obtains images with very fine details. The Zenmuse X4S Burst mode operates at 14 fps and 20 megapixels in both JPEG and DNG formats. It strikes the delicate balance between agility and image quality.

Carrying out inspections remotely, without the need to get closer is not simply a saving of time and efficiency of operations. The risk of collision is also extremely reduced.

The Zenmuse Z30 is designed for use with the Lightbridge 2, pushing the technical limits of transmission range to 5 km (3.1 miles).

Lightbridge 2 sets a new standard for remote HD image transmission with its integrated controllers and intelligent algorithms that decrease latency and increase image fidelity.

The Zenmuse XT2 camera incorporates a FLIR thermal sensor (uncooled VOx microbolometer)  high-resolution camera and a 4K visual camera. DJI's cutting-edge stabilization and mechanical intelligence technology quickly transforms aerial data into useful information. The advanced thermal sensor provides high-sensitivity imaging for infrastructure surveillance, energy inspections, firefighting, search and rescue missions, among other applications. The fully integrated dual payload enables professionals to capture thermal data and color images in a single flight, which not only saves time and money, but sometimes saves human lives.

- Thermal sensor resolution: 640 × 512
-  Distance between pixels: 17  µm
- Thermal sensitivity (NEDT): <50MK@f/1.0
- Color and monochrome palettes (LUT):  Yes
- Digital Detail Enhancement (DDE):  Yes
-  Spectral band: 7.5-13.5 µm
- High gain range: -25  ° C to 135  ° C
- Low gain range: -40  ºC to 550  ºC
- Angular vibration range: ± 0.01 °
- Refresh rate max. : 30HZ
- Optical sensor: 12MP and 4K video
- Protection index: IP44 level

Temp Alarm

Don't miss a thing with instant notifications when objects exceed the indicated temperature.

Heat Track

Collect the most important information by locking the orientation of the XT2 towards the hottest object in the field of view.

FLIR MSX® Multispectral Dynamic Imaging

MSX intelligent image processing improves perspective and safety by overlaying visible image edge details over thermal images.

• Flight near people, within 100 feet (30m) and up to 16.4 feet (5m)

• Over people, within 16.4 feet (5m)

• Controlled airspace

The Inspire 2 takes all the advantages of the first model and improves upon them. The CineCore 2.0 image processing system has been upgraded to version 2.1.

Video recording is compatible with 6K in CinemaDNG / RAW and with 5.2K in Apple ProRes when the Zenmuse X7 camera is used.

​

With the Zenmmse X5S equipped with a Micro 4/3 sensor, the dynamic range of the Zenmuse X5S is 12.8 stops and the color sensitivity and signal-to-noise ratio are much higher than that of the X5R. It is compatible with eight standard M4 / 3 lenses (including zooms) with focal lengths ranging from 9mm to 45mm (equivalent to 18 - 90mm on a 35mm camera) for more creative flexibility.

The Inspire 2's new image processing system, CineCore 2.0, gives the Zenmuse X5S the ability to shoot 5.2K 30 fps CinemaDNG and Apple ProRes *, 4K 60 fps H.264 and 4K 30 fps H .265 (both at 100 Mbps). Burst mode continues DNG at a frame rate of 20 fps with 20.8 MP frames. The Zenmuse X5S has been designed to keep pace with the working conditions of aerial imagery professionals.

​

It goes from 0 to 80 km / h (50 mph) in just 5 seconds and reaches a maximum of 94 km / h (58 mph). Its maximum descending speed is 9 m / s. Such speed and agility for an aircraft of this size is a first.

A dual battery system extends flight time to a maximum of 27 minutes (with the X4S) and the self-heating technology allows it to fly even in very low temperatures.

FlightAutonomy has been reviewed and developed specifically for the Inspire 2, allowing obstacle avoidance in two directions and sensor redundancy. Multiple intelligent flight modes have been enhanced, like Spotlight Pro, to give pilots the ability to create complex and dramatic shots.

​

The improved video transmission system is now capable of transmitting on two channels, with double the signal frequency. It can broadcast video feed from on-board FPV camera and main camera simultaneously for better collaboration between pilot and cameraman.

• Flight near people, within 100 feet (30m) and up to 16.4 feet (5m)

• Over people, within 16.4 feet (5m)

• Controlled airspace

Visionary intelligence and sublimated imagination.

The camera is equipped with a 1-inch 20-megapixel sensor capable of taking 4K / 60fps video and 14fps burst mode photos.

The FlightAutonomy system includes 5 optical sensors to detect obstacles in 2 directions and avoid those ahead.

The choice of an alloy of titanium and magnesium increases the rigidity of the chassis and reduces the weight, making the Phantom 4 Advanced lighter than the Phantom 4.

​

​

Composed of 5 optical sensors, GPS and GLONASS satellite positions, ultrasonic sensors and a redundancy system, the FlightAutonomy system gives the Phantom 4 Advanced the ability to hover with precision, even in places without a GPS signal, and fly in complex environments.

The two front optical sensors see up to 30m in front of the device. It can brake automatically, hover in front of obstacles or circle them, when they are within a radius of 15 m.
